Beschreibung
Prophet-5 Module SpecificationsOSCILLATORSTwo authentic CEM 3340 voltage-controlled oscillators per voiceSimultaneously selectable wave shapes. Oscillator A: sawtooth, pulse. Oscillator B: sawtooth, triangle, pulse.Pulse width per oscillatorHard sync: Oscillator A syncs to Oscillator BLow frequency mode (Oscillator B)Keyboard tracking on/off (Oscillator B)MIXEROscillator A amountOscillator B amountWhite noise amountLOW-PASS FILTERFour-pole, resonant, low-pass filter per voiceSwitchable between authentic versions of the Prophet-5 Rev1/2 filter and Prophet-5 Rev3 filterRev1/2 filter is a Dave Rossum-designed 2140, the modern counterpart of the original 2040 filter found in the Prophet-5 Rev1 and Rev2Rev3 filter is a Doug Curtis-designed CEM 3320Filter can be driven into self-oscillation with the Resonance controlKeyboard tracking: off, half, fullFILTER ENVELOPEFour-stage (ADSR) envelope generatorVelocity modulation of envelope amountAMPLIFIER ENVELOPEFour-stage (ADSR) envelope generatorVelocity modulation of envelope amountLOW FREQUENCY OSCILLATORThree wave shapes: sawtooth, triangle, square. All waveshapes can be engaged simultaneouslyBoth Initial Amount and mod wheel controlMod destinations: oscillator A frequency, Oscillator B frequency, Oscillator A and B pulse width, filter cutoffPOLY MODSources: filter envelope and Oscillator BDestinations: Oscillator A frequency, Oscillator A pulse width, filter cutoffVINTAGE KNOBRecreates the characteristics of various Prophet-5 models by varying the behavior of oscillators, envelopes, amplifiers, and other parameters. Go from a very stable “4” — as in Prophet-5 Rev4, (the new version) — all the way to “1,” as in Prophet-5 Rev1, the rarest and most temperamental of all Prophet-5s.AFTERTOUCHChannel (mono) aftertouchDestinations: filter cutoff frequency, LFO amountPERFORMANCE CONTROLSPolyphonic glide (portamento)Unison (monophonic) mode with configurable voice count, from one to all five voices and key modesPreset switch: when off, the front panel is live; what you see is what you hearPATCH MEMORY200 user and 200 factory programs in 5 banks of 40 programs eachDirect program access, including Prophet 5-style single-button access to the current set of 8 programsIN/OUTMono output (1 x 1/4” phone jack)Headphone output (stereo, 1/4” phone jack)MIDI in, out, and thru portsUSB for bidirectional MIDI communicationControl voltage in/out (1 x 1/4” phone jack) 0- +5V input/output signal. Configured for 1-volt-per-octave operation.Gate in/out (1 x 1/4” phone jack). Accepts a 1.5 to 15-volt on/off signal to gate the envelopes of a single voice on the Prophet-5. Outputs a 15-volt on/off used to gate the envelopes of an external synth.Low-pass filter cutoff expression pedal inputVolume expression pedal inputSustain footswitch inputPOWERIEC AC power inlet for internal power supplyOperates worldwide on voltages between 100 and 240 volts at 50 to 60 Hz; Prophet-5: 20 watts maximum power consumption.PHYSICAL SPECS20.75″ L x 7.4″ W x 3″ H (52.70 cm x 18.8 cm x 7.62 cm)Roadworthy all-steel case with premium black walnut heartwood trim
