Beschreibung
includes the dual SFP I/O mini-module and a 0,8m certified TB3 cableFeaturesThunderbolt 3 interface, with 256 Bidirectional Channels at 48 & 96 kHz, 128 channels at 192 kHz and 64 channels at 384 kHz.Main and expansion Thunderbolt 3 Port w. 15W Power Source Each. Both of the two Thunderbolt 3 ports can function as main and expansion port. Audio Drivers for macOS and Windows.MADI interface on BNC connectors with 64 Bidirectional Channels at 48kHz, 32 channels at 96kHz, 16 channels at 192 kHz and 8 channels at 384 kHz.Dual ADAT interface on TosLink Light pipes with 16 Bidirectional Channels at 48kHz, 8 channels at 96kHz, and 4 channels at 192 kHz. Configurable also as 2 Ch. S/PDIF input.DANTE AoIP interface via Ethernet with 256 Bidirectional Channels at 48 and 96kHz, 128 channels at 192 kHz.Module Slot for optional dual Madi module via 2 x SFP (LC Fiber or HD/BNC Coax) connectors with 128 Bidirectional Channels at 48kHz, 64 channels at 96kHz, 32 channels at 192 kHz and 16 channels at 384 kHz. wo card slots available for DAD I/O Expansion Cards.Word Clock I/O, and Video Black and Burst input on BNC connectors.128 channels speaker processing with a total of 1024 filters and delay.Summing Processor 64 Output / 512 Input Busses.Internal Router: 4096 x 4096.32bit Floating Point Processing.DADman control software for macOS and Windows connecting via Ethernet or Thunderbolt. Pro|Mon monitor control functionality and integration for Avid Eucon Enabled Devices via DADman.19” Rack Unit 1U Height.Technical Overview2 Ch. microphone or instrument inputDual stereo headphone outputDual stereo monitor outputA/D, D/A and D/D Converter with sample rates from 44,1 to 384 kHz and DSDUp to 984 Input and Output ChannelsRouter and Monitoring Interface Thunderbolt 3 I/O (256 Ch.)Dante AoIP I/O (256 Ch.)MADI I/O (64 ch.)ADAT I/O (16 Ch.) / SPDIF (2 ch.)2 Slots for Optional Multi-Format DAD I/O Cards512x64 Ch. Pro|Mon Summing and Speaker 1024 ch. EQ Processing
